Any1 familiar with editing invoice layout here ?

[SG_Jimmy]

http://img.photobucket.com/albums/v189/sg_jimmy/invoice.png



Hi guys need some help to change something on my invoice which im going to use as a PO.



1) How can i remove those 3 wording at the side of invoice I have highlighted in red.



2)

a)How can i remove the unit purchased being in front of the Item Description

b)how can I add 1 more column for unit



3 I just want the tax to be show Item Description, unit purchased, unit price and total unit price.

isit possible to remove the tax column of individual item ? i just want the tax to be shown @ bottom right



thanks guys

[♥bruyndoncx]

yes, that is all very easy



the top and bottom line is your internetbrowser that prints header and footer elements, check your page setup in IE



the invoice details are in table rows (TR elements) and table data cells (TD elements)



If you find the <TD> </TD> combo's, you can remove them or move them around as you see fit.



you have a TR line for the column headers, and for each product within a while loop.



Just make a copy of the invoice and start experimenting

[SG_Jimmy]

yes, that is all very easy



the top and bottom line is your internetbrowser that prints header and footer elements, check your page setup in IE



the invoice details are in table rows (TR elements) and table data cells (TD elements)



If you find the <TD> </TD> combo's, you can remove them or move them around as you see fit.



you have a TR line for the column headers, and for each product within a while loop.



Just make a copy of the invoice and start experimenting



Thanks i solve the page top and bottom line issue.



can u tell me where can i find the invoice file and please be more specific

[♥14steve14]

Look in admin/invoice.php.

[SG_Jimmy]

Look in admin/invoice.php.



thanks i found the invoice file,

Can any1 guide me on how to move the unit from front of the item to a column

[SG_Jimmy]

Hi I have try many time but still fail. I have attached my invoice file if any1 can help :)



invoice.php

[♥14steve14]

Tried to break this down for you, to see what was happening and why.



To seperate the quantity from the price and to create a new column name before the product name



Find



<tr class="dataTableHeadingRow">

<td class="dataTableHeadingContent" colspan="2"><?php echo TABLE_HEADING_PRODUCTS; ?></td>



and change it to



<tr class="dataTableHeadingRow">

<td class="dataTableHeadingContent"><?php echo TABLE_HEADING_PRODUCTS_QTY; ?></td>

<td class="dataTableHeadingContent" colspan="2"><?php echo TABLE_HEADING_PRODUCTS; ?></td>



To create the new column showing the quantity



Find



for ($i = 0, $n = sizeof($order->products); $i < $n; $i++) {

echo ' <tr class="dataTableRow">' . "\n" .

' <td class="dataTableContent" valign="top" align="right">' . $order->products[$i]['qty'] . ' x</td>' . "\n" .

' <td class="dataTableContent" valign="top">' . $order->products[$i]['name'];



and change it to



for ($i = 0, $n = sizeof($order->products); $i < $n; $i++) {

echo ' <tr class="dataTableRow">' . "\n" .

' <td class="dataTableContent" valign="top">' . $order->products[$i]['qty'] . '</td>' . "\n" .

' <td class="dataTableContent" valign="top">' . $order->products[$i]['name'];



To move the total column over one column to realign



Find



<td align="right" colspan="8"><table border="0" cellspacing="0" cellpadding="2">



and change it to



<td align="right" colspan="9"><table border="0" cellspacing="0" cellpadding="2">



In your admin/includes/languages/english/invoice.php



find



define('TABLE_HEADING_PRODUCTS', 'Products');



and change to



define('TABLE_HEADING_PRODUCTS_QTY', 'Qty');

define('TABLE_HEADING_PRODUCTS', 'Products');



I think you can also do something similar to the packing slip page as well.
